Towed engine-driven compressor MC 650

MC 650

Level of professional

Line:

PROFESSIONAL Line

Category:

Pneumatic

Product type:

Engine-driven compressors

The MC 650 engine-driven compressor, designed for a highly professional use, is available with a diesel engine and has the best performance to dimensions ratio. The strong head block can power supply several tools at the same time.

Weight

123,2 kg

Pressure

9/11 bar max

Intake air

582 l/min

Size

83 x 72 x 88 cm

Power supply

KD15-350 6.8 HP Kohler diesel engine

Tank capacity

11+11 l

Amount of plug-in scissors

4/5

Amount of plug-in harvesters

Amount of plug-in pruners

CHARACTERISTICS	MC 650 Kohler KD15-350 6.8 HP
AIR DISPLACEMENT	582 l/min
CYLINDERS QUANTITY	2
STAGES QUANTITY	2
AIR TANK CAPACITY	11+11 l
MAXIMUM TANK WORKING PRESSURE	9/11 bar max
DIMENSIONS	83x72x88 cm
TOTAL WEIGHT	123,2 kg
QUANTITY OF POWERED SHEARS	4/5
QUANTITY OF POWERED HARVESTERS	3
QUANTITY OF POWERED PRUNERS	1

Other technical details

Honda and Campagnola gasoline engine and Kohler / Lombardini diesel engine

Automatic self-regulating device for the engine rpm. It accelerates or slows down the engine according to the air need, drastically reducing the consumptions

1/4” and 3/8” anti-condensation filter with pressure regulator and lubricator

Made in Italy head blocks

Copper hoses for a better heat dispersion

Automatic pilot valve/unloader

Double tank to separate air and water and to avoid any tool freezing

12 bar homologated tanks (the homologated pressure has to be higher than the working pressure)
